Industrial conveyor belt manufactured by Mohammadi Machine Industries

Continuous material transfer between crushing, screening and stockpiling stages

1 / 1

Mohammadi Machine Industries Products

Conveyor Belt

Name: Conveyor Belt
Brand: Mohammadi Machine Industries

The Mohammadi industrial conveyor belt provides continuous transfer of stone, aggregate and mineral material between production stages. Belt width, length, incline, drive power, idler arrangement and supporting structure are engineered around the required capacity, material characteristics and plant layout.

Custom length and belt width

Capacity matched to the production line

Serviceable idlers and pulleys

Fixed or mobile configuration

Call for Technical Advice & Quotation Send Project Specifications on WhatsApp

Technical Product Overview

What is an industrial conveyor belt and where is it used?

A conveyor belt connects individual machines and keeps material moving at a controlled rate. In a crushing plant, it may transfer feed from the feeder to a crusher, carry crushed product to the vibrating screen, or deliver classified aggregate to a stockpile.

Correct design depends on bulk density, maximum lump size, moisture, required throughput, horizontal distance, lift height, incline and operating hours. These inputs determine the belt specification, conveyor geometry, drive system, pulley and idler selection, loading point and discharge arrangement.

Reliable conveying is a system result: belt selection, loading geometry, tension, alignment, drive sizing and structural support must all match the actual material and duty cycle.

Crusher InterconnectionsTransfers material between primary, secondary and tertiary crushing stages.

Screening CircuitsFeeds screens and returns oversize material in closed-circuit layouts.

StockpilingMoves finished aggregate to storage piles or loading points.

Fixed and Mobile PlantsCan be configured for permanent lines or relocatable installations.

Key Advantages

Main advantages of a correctly designed conveyor belt

Actual performance depends on selecting each component for the material, capacity, route and operating environment.

Continuous Transfer

Maintains a steady material flow and reduces repeated loader handling between machines.

Replaceable Components

Idlers, rollers, belt and wear-zone parts can be inspected and serviced individually.

Project-Matched Drive

Motor, gearbox and pulley arrangement are selected for the load, length and incline.

Custom Structure

Frame, supports, walkways and guards can be adapted to the installation location.

Operating Process

How does a conveyor belt work?

An electric motor and gearbox rotate the drive pulley. Friction between the pulley and tensioned belt moves the carrying surface, while idlers support the loaded and return strands. Material enters through a controlled loading point and leaves at the head pulley or a designed discharge station.

Controlled LoadingMaterial enters the belt through a chute designed to reduce impact and spillage.

Supported TransportCarrying idlers support the belt and maintain the required cross-sectional profile.

Drive and DischargeThe drive pulley moves the belt and material discharges at the selected point.

Return and TrackingReturn idlers guide the empty belt back while tensioning maintains stable travel.

Project-Specific Configuration

Technical specifications and options for conveyor belts

Final values are confirmed after reviewing the required capacity, material data, route geometry, installation space and upstream and downstream equipment.

Installation Type: Fixed, mobile or semi-mobile according to the plant layout
Conveyor Length: Engineered for the required transfer distance and support locations
Belt Width and Grade: Selected for throughput, lump size, abrasion and operating conditions
Capacity: Matched to peak and normal production rates
Drive System: Electric motor, gearbox and pulley sized for load, speed and incline
Idlers and Structure: Duty-rated rollers, pulleys, frame and supports
Optional Equipment: Loading chutes, covers, walkways, guards, scrapers and emergency stops

Selection and Purchase Guide

What information is required before ordering a conveyor belt?

Accurate project information prevents undersizing, belt mistracking, excessive spillage and unnecessary energy use.

Material Data

Provide bulk density, maximum lump size, moisture and abrasiveness.

Required Capacity

State normal and peak throughput rather than only the average rate.

Route Geometry

Define center distance, elevation change, incline and discharge position.

Site Conditions

Identify dust, rain, temperature, mobility and access requirements.

Maintenance and Operation

How to extend conveyor belt service life

Routine inspection and prompt correction of alignment, tension and component wear help prevent belt damage and unplanned shutdowns.

Check belt tracking, tension and splice condition

Inspect idlers and replace seized or damaged rollers

Monitor drive and tail pulley bearings and alignment

Remove material buildup around loading and return areas

Keep guards, pull-cords and emergency stops operational

Frequently Asked Questions

Frequently Asked Questions About Conveyor Belt

Concise answers to important questions about selection, operation, maintenance and quotation.

It is selected from required capacity, material bulk density, lump size, belt speed, trough profile and loading conditions.

Yes. Length, width, support spacing and discharge height are engineered to the installation layout.

Common causes include misaligned pulleys or idlers, uneven loading, material buildup, incorrect tension and a damaged splice.

A mobile or semi-mobile arrangement can be designed when relocation, temporary operation or changing stockpile positions are required.

The main factors are length, width, belt grade, capacity, drive power, structural steel, idlers, pulleys and requested accessories.
